ATARU Black — High-Temp DLP Resin

ATARU Black by Nano Dimension is a groundbreaking UV-curable resin for DLP printing. Part of the ATARU series, it combines exceptional high-temperature resistance, durability, superior surface quality, and ultra-low dielectric loss with enhanced precision down to the printer's pixel size.

Key Benefits

• Market-leading thermal performance — HDT >300°C (0.45 / 1.8 MPa), Tg >300°C
• High impact strength and durability; suitable for injection molding
• Ultra-low dielectric loss — ideal for high-frequency / RF applications
• Enhanced precision — excellent accuracy on fine features, scalable after post-processing
• Low viscosity (~885 mPas) — seamless integration across a wide range of 365–405nm DLP printers
• Fast processing, suitable for serial production

Ideal Applications

• Connectors for electronics
• Molds (injection molding)
• Tools & fixtures
• Radio frequency (antenna) components

Mechanical & Thermal Properties

• Tensile Modulus: 5790 MPa (ISO 527)  |  Stress at break: 69 MPa
• Flexural Modulus: 5190 MPa  |  Flexural Strength: 121 MPa (ISO 178)
• Izod impact, unnotched: 170 J/m (ASTM D4812)
• Tg: >300°C  |  HDT/B (0.45 MPa) & HDT/A (1.8 MPa): >300°C  |  HDT/C (8.0 MPa): 133°C
• Td2: 367°C  |  Td5: 391°C
• Color: Black  |  Viscosity: ~885 mPas @ 23°C

Print Process

• Wavelength: 365–405nm
• Exposure @405nm: 2.7 mW/cm² = 12.5s; 5.5–16 mW/cm² = 2.3s; base layer 10–15s
• Post-cure: any UV treatment (no overcuring risk); thermal post-treatment 2h @200°C, cool slowly
